Structural Organization of Skeletal Muscle

Skeletal muscle is also known as voluntary muscle because we can consciously, or voluntarily, control it in response to input by nerve cells. However, and somewhat ironically, most of the daily control of skeletal muscle is reflexive, or unconsciously controlled! More on that regulation later. Skeletal muscle is also referred to as striated ("striped") because it has a microscopically streaked or striped appearance. Skeletal muscle and its associated connective tissue comprise about 40% of our body weight. Skeletal muscle also has a unique characteristic with regard to nuclei.  There are many nuclei in each skeletal muscle cell. These nuclei are generally pressed up against the cell membrane as there is very little room inside the cells given all the contractile proteins that are there.

Skeletal Muscle Organization. Image drawn by BYU-Idaho student Nate Shoemaker Spring 2016
Image drawn by BYU-Idaho student Hannah Crowder Spring 2013

Each skeletal muscle cell, also called a muscle fiber, develops from many embryonic myocytes fused into one long, multi–nucleated skeletal muscle cell. These muscle fibers are bound together into bundles, or fascicles, and are supplied with a rich network of blood vessels and nerves. The fascicles are then bundled together to form the intact muscle. Muscle fibers are the same diameter as hair follicles (100-120um). As you look down at your bicep, visualize small strands of hair follicles extending from your shoulder to the radius bone in your forearm. Clearly, one hair follicle would be too fragile to move your arm, but hundreds of millions are very adequate! Let's dissect a skeletal muscle, beginning with the muscle as a whole externally and continuing internally down to the submicroscopic level of a single muscle cell. In an intact skeletal muscle, a rich network of nerves and blood vessels nourish and control each muscle cell. These muscle fibers are individually wrapped and then bound together by several different layers of fibrous connective tissue.

The epimysium (epi means “outside,” and mysium means “muscle”) is a layer of dense fibrous connective tissue that surrounds the entire muscle. This layer is also often referred to as the fascia. Each skeletal muscle is formed from several bundled fascicles of skeletal muscle fibers, and each fascicle is surrounded by perimysium (peri means “around”). Each single muscle cell is wrapped individually with a fine layer of loose (areolar) connective tissue called endomysium (endo means “inside”). These connective tissue layers are continuous with each other, and they all extend beyond the ends of the muscle fibers themselves, forming the tendons that anchor muscles to bone, moving the bones when the muscles contract.

Deep to the endomysium, each skeletal muscle cell is surrounded by a cell membrane known as the sarcolemma (you will see the prefixes sarc- and myo- quite a bit in this discussion, so you should understand that these are prefixes that refer to "muscle"). The cytoplasm, or sarcoplasm, contains a large amount of glycogen (the storage form of glucose) for energy, and myoglobin (a red pigment similar to hemoglobin that can store oxygen). Most of the intracellular space, however, is taken up by cylindrical (rod-like) myofibril protein structures. Each muscle fiber contains hundreds or even thousands of myofibrils that extend from one end of each muscle fiber to the other. These myofibrils take up about 80% of the intracellular space and are so densely packed inside these cells that mitochondria and other organelles get sandwiched between them while the nuclei get pushed to the outside and are located on the periphery, right under the sarcolemma.

Each myofibril is comprised of several varieties of protein molecules that form the myofilaments, and each myofilament contains the contractile segments that allow contraction. These contractile segments are known as sarcomeres (sarc- means “muscle,” and mere means “part”). The striations seen microscopically within skeletal muscle fibers are formed by the regular, organized arrangement of myofilaments—much like what we would see if we painted stripes on chopsticks and bundled them together with plastic wrap, with the plastic wrap representing the sarcolemma.

The striations microscopically visible in skeletal muscle are formed by the regular arrangement of proteins inside the cells. Notice that there are light and dark striations in each cell. The dark areas are called A bands, which is fairly easy to remember because "A" is the second letter in "dark." The light areas are called I bands and are also easy to remember because "i" is the second letter in "light." ("A" actually stands for anisotropic, and "I" stands for isotropic. Both of these terms refer to the light absorbing character of each band. However, we'll stick to A and I bands.) The image below shows a micrograph of a sarcomere, along with a drawing representing the different parts of the sarcomere.

Sarcomere filaments and their striated appearance
Skeletal Muscle Sarcomere: Thick and Thin Filaments, Z Line, H Zone, I & A Bands.  File:Sarcomere.gif; Author: Sameerb; Site: https://commons.wikimedia.org/wiki/File:Sarcomere.gif; License: Public Domain, No restrictions

Notice that in the middle of each I band is a darker line called the Z line or Z disc. The Z lines are the divisions between the adjacent sarcomeres. Sarcomeres are connected, end to end, along the entire length of the myofibril. Also, in the middle of each A band is a lighter H zone (H for helle, which means "bright"), and each H zone has a darker M line (M for "middle") running right down the middle of the A band.

Sarcomere filaments
Sarcomere: Detailed Illustration of Thick and Thin Filaments: Title: 1003_Thick_and_Thin_Filaments.jpg; Author: OpenStax College; Site: http://cnx.org/contents/6df8aab3-1741-4016-b5a9-ac51b52fade0@3/Skeletal-Muscle;License: licensed under a Creative Commons Attribution 4.0 License.

Each myofibril, in turn, contains several varieties of protein molecules, called myofilaments. Myofilaments can be divided into three categories: scaffolding proteins (Z-disc, nebulin, titin, tropomodulin, alpha-actinin and CapZ proteins), contractile proteins (actin and myosin), and regulatory proteins (troponin and tropomyosin).

Let's discuss each myofilament category in turn. Scaffolding proteins serve to demarcate the sarcomere.

Z-disc proteins make up the Z-line that create perpendicular borders that form the repeating sarcomeres. CapZ and alpha-actinin anchor the protein nebulin to the Z line and extend out to the center where the length is capped off by the protein tropomodulin. Alternating between molecules of nebulin is the elastic protein called titin. Titin is thought to play a major role in resetting the sarcomere after each contraction. Thus, each sarcomere consists of alternating nebulin and titin proteins that set the stage for the organization of the contractile and regulatory proteins.

Each actin is composed of two strands of fibrous actin (F-actin) and a series of troponin and tropomyosin molecules. Each F-actin (also known as the thin filament) is formed by two strings of globular actin (G-actin) wound together in a double helical structure, much like twisting two strands of pearls with each other. Each G-actin monomer starts with a binding site for ATP that it uses to polymerize to another G-actin monomer and nebulin. Following polymerization of G-acting monomers to form F-actin strands, the original ATP binding site is altered and becomes a binding site for the molecule myosin, called an active site. Dimers of the protein tropomyosin extend over the entire F-actin filament and cover the newly created myosin binding sites. Each tropomyosin molecule is long enough to cover the active binding sites on seven G-actin molecules. These proteins run, end to end, along the entire length of the F-actin. Associated with each tropomyosin molecule is a third polypeptide complex known as troponin. Troponin complexes contain three globular polypeptides (Troponin I, Troponin T, and Troponin C) that have distinct functions. Troponin I binds to actin, troponin T binds to tropomyosin and helps position it on the F-actin strands, and troponin C binds calcium ions. Troponin C has four binding sites for calcium, two high-affinity binding sites and two low-affinity-binding sites. At low intracellular Ca2+  concentrations the high-affinity binding sites are occupied and help maintain the stability of the troponin complex. When intracellular calcium concentrations rise, then the low-affinity binding sites are occupied which causes a conformational change in the entire complex. This conformation change will result in troponin “pulling” the tropomyosin molecule away from the myosin binding sites of actin.

The final contractile myofilament (also called the thick filaments) is composed of about 300 myosin type II molecules bound together and surrounding the molecule titin. Each myosin type II protein is made up of six protein subunits, two heavy chains and four light chains. The heavy chains have a shape similar to a golf club, having a long shaft-like structure, to which is connected the globular myosin head. The shafts, or tails, wrap around each other and interact with the tails of other myosin molecules, forming the shaft of the thick filament. The globular heads project out at right angles to the shaft. Half of the myosin molecules have their heads oriented toward one end of the thick filament, and the other half are oriented in the opposite direction. It is the myosin heads that bind to the active sites on the actin. The connection between the head and the shaft of the myosin molecules function as a hinge and as such is referred to as the hinge region. The hinge region can bend and, as we shall see later, creates the power stroke when the muscle contracts. The center of the thick filament is composed only of the shaft portions of the heavy chains.

Additionally, each myosin head has an ATPase that binds to and hydrolyzes ATP during muscle contraction. It is the ATP that provides the energy for muscle contraction. Each of the myosin heads is associated with two myosin light chains, an alkali light chain and a regulatory light chain, that play a role in regulating the actions of the myosin heads. The three-dimensional arrangement of the myosin heads is very important. Imagine that you were looking at a thick filament from the end, and there is a myosin head sticking straight up. As you moved around the circumference of the thick filament, you would see myosin heads every 30 degrees. This allows each thick filament to interact with six thin filaments. Likewise, each thin filament can interact with three thick filaments. This arrangement requires that there be two thin filaments for every thick filament in the myofibril (see image below).

Muscle Fiber Organization
Muscle Fiber Detailed Diagram. Adapted from the following image: Title: 1022_Muscle_Fibers_(small).jpg; Author: OpenStax College; Site: http://cnx.org/contents/6df8aab3-1741-4016-b5a9-ac51b52fade0@3/Skeletal-Muscle License: licensed under a Creative Commons Attribution 4.0 License;

During muscle contraction, the myosin heads link the thick and thin myofilaments together, forming cross bridges that cause the thick and thin myofilaments to slide over each other, resulting in a shortening of each sarcomere, each skeletal muscle fiber, and the muscle as a whole—much like the two parts of an extension ladder that slide over each other. To summarize, in order for the shortening of the muscle to occur, the myosin heads have three important properties: 1.) The heads can bind to active sites on G-actin molecules, forming cross bridges. 2.) The heads are attached to the rod-like portions of the heavy myosin molecules by a hinge region as already discussed. 3.) The heads have ATPase enzymes that can break down ATP, using the resulting energy to bend the hinge region and allow detachment of the myosin heads from actin.

There are several other important structural proteins, but we will only discuss one more: dystrophin. Dystrophin is a protein located between the sarcolemma and the outermost myofilaments. It links actin to an integral membrane protein, which, in turn, links the muscle cell to the endomysium of the entire muscle fiber. Genetic mutation of the gene coding for dystrophin is one of the root causes of a class of muscle diseases known collectively as muscular dystrophy (MD). The most common form of MD is Duchene muscular dystrophy (DMD), which is inherited in a "sex-linked" fashion and affects boys. Most DMD patients become wheelchair bound early in life, usually by age 12 or so. Difficulty breathing usually becomes problematic by age 20 and sadly is often the cause of their premature death.

Sarcoplasmic Reticulum and T Tubules

T-tubules and sarcoplasmic reticulum
T-Tubule. Title: 1023_T-tubule.jpg; Author: OpenStax College; Site: http://cnx.org/contents/6df8aab3-1741-4016-b5a9-ac51b52fade0@3/Skeletal-Muscle; License: licensed under a Creative Commons Attribution 4.0 License

There are two sets of tubules within skeletal muscles fibers that carry out critical functions during muscle contractions: the sarcoplasmic reticulum and the T-tubules.

T-tubules (transverse tubules) are invaginations, or indentations, of the sarcolemma. They are formed much like a young picky-eater poking holes in his mashed potatoes. T-tubules communicate with the extracellular space and are filled with extracellular fluid. They are located on the sarcomere at the point where the A band and I band overlap. The T-tubules are flanked on either side by dilated regions of the cell's endoplasmic reticulum—the sarcoplasmic reticulum.

Sarcoplasmic reticulum (SR) is an elaborate network of smooth endoplasmic reticulum that surrounds and encases each myofibril, much like a loosely knitted sweater that covers your arms. It stores calcium which can then be released into the sarcoplasm when an action potential is conducted along the sarcolemma of the T-tubule. Most of the sarcoplasmic reticulum runs parallel to the myofibrils, but there are right-angle enlargements of the SR at the A band/I band junctions that flank the T-tubules. These enlargements are known as terminal cisternae ("end sacs") (see the image above). One T-tubule along the two terminal cisternae that parallel it form the triad. The triad is critical in skeletal muscle function. At each triad, the T-tubule membrane contains large numbers of voltage-dependent proteins called dihydropyridine (DHP) channels or L-type calcium channels. Although these are called channels, they do not allow calcium to move through them; rather, they are physically linked to calcium release channels on the terminal cisternae known as ryanodine receptor channels (RyR). When the membrane is depolarized by an action potential, the DHP channel detects a depolarization and causes the RyR channels to open, resulting in the release of calcium from the terminal cisternae of the SR. To ensure a large concentration gradient for calcium is present at the terminal citsterna, each ryanodine channel as an addition protein linked to it called calsequestrin. This protein binds up calcium ions so that they don’t diffuse throughout the long network of tubes of the sarcoplasmic reticulum. The binding is very low affinity, but enough to keep calcium ions near the channel. This arrangement ensures that once the ryanodine channel is triggered to open, there will be a substantial calcium gradient to exit through the channel and into the sarcoplasm.
