8 - Polymerase Chain Reaction (PCR)
PCR Reaction Components
The polymerase chain reaction (PCR) is essentially DNA replication in a test tube. In the laboratory, PCR can be used to copy or amplify any DNA sequence of interest. PCR has a myriad of applications. For example, PCR can be used in forensics to make copies of the DNA molecules left by a suspect at a crime scene, scientists can use PCR to make many copies of a gene to study gene function, and finally, PCR can be used to determine if an individual is infected with a microbe, such as the human immunodeficiency virus (HIV) or SARS-CoV-2 (the virus that causes COVID-19).
Suppose our goal is to study the human β-globin gene, which produces one of the protein subunits of hemoglobin. We would likely use PCR to make millions of copies of the β-globin gene as part of our research. To accomplish this goal, our PCR reaction would contain the following components:
- Template DNA. This template DNA molecule includes the gene or segment of DNA that is to be copied (amplified). In our scenario, the template DNA would be the chromosome that contains the human β-globin gene.
- DNA primers. These two single-stranded DNA primers (each approximately 20 nucleotides in length) are designed by the scientist to bind to the template DNA molecule on each side of the gene that will be amplified by PCR. In our scenario, one DNA primer would bind to the left of the β-globin gene on one of the template DNA strands, the other DNA primer would bind to the right of the β-globin gene on the other template DNA strand.
- dNTPs (dATP, dCTP, dTTP, and dGTP). The dNTPs provide the energy for DNA replication via PCR. The nitrogenous base, the deoxyribose sugar, and one of the phosphate groups in each dNTP is also incorporated into the growing daughter DNA strand.
- Thermostable DNA polymerase. PCR uses a DNA polymerase called Taq polymerase, isolated from the thermophilic bacterium Thermus aquaticus. Taq polymerase is a thermostable DNA polymerase that functions similarly to DNA polymerase I from E. coli. A thermostable DNA polymerase is used because PCR involves a series of heating steps (see below) that would denature other DNA polymerases, including all of the DNA polymerases discussed in Part 6.
- Buffer. The buffer component maintains the proper pH for the PCR reaction and contains enzyme cofactors, such as magnesium ions, necessary for Taq polymerase activity.
- What are the functions of the five major components of a PCR reaction?
Once the PCR reaction is prepared with each of the five components above, the PCR reaction is subjected to multiple PCR cycles (see figure 8.1). Each PCR cycle has the following steps:
- The template DNA is denatured by heat treatment (95°C for 1 minute). The denaturing step causes the individual template DNA strands to separate from each other.
- The DNA primers anneal (form hydrogen bonds) with complementary sites on the template DNA strands (55°C for 1 minute).
- Taq polymerase synthesizes DNA (72°C for 2 - 3 minutes). Taq polymerase synthesizes the daughter DNA strands by adding dNTPs to the free 3’-OH groups provided by the primers.
Each PCR cycle described above is repeated typically 30-35 times. The number of DNA molecules is doubled at the conclusion of each cycle. The number of copies of the target DNA sequence made during PCR can be estimated using the following equation:
n = a x 2b
- n = the number of copies of the target DNA sequence made during PCR.
- a = the number of template DNA molecule at the beginning of the PCR experiment
- b = the number of PCR cycles that have passed.
In the lab, the PCR cycles are accomplished by mixing the above five reaction components in a tube, followed by placing the reaction in a device called a thermocycler. The thermocycler automates the number of cycles, the temperature of each step within a cycle, and the length of each step within a cycle.
- What events occur during each of the three steps in a typical PCR cycle?
- Describe how PCR can be used to amplify a gene of interest.
Agarose Gel Electrophoresis
Agarose gel electrophoresis is a method used in the laboratory to separate DNA molecules from each other based upon the size (see Figure 8.2). For our purposes, agarose gel electrophoresis can be used to determine whether the PCR experiment successfully copied (amplified) the β-globin gene and can be used to analyze the size (in base pairs) of the β-globin PCR product.
To perform an agarose gel electrophoresis experiment:
- The agarose gel is prepared. To prepare a gel, the agarose (a polysaccharide powder purified from marine algae) is dissolved in a buffer by heating in a microwave. This molten agarose solution is then poured into a plastic mold and allowed to cool to form a gel. The resulting agarose gel contains a meshwork (matrix) of agarose polymers. The consistency of the matrix depends on the concentration of agarose used. High agarose concentrations produce a matrix with small pores, useful for separating small DNA molecules. Low agarose concentrations produce a matrix with larger pores, useful for separating large DNA molecules. A fluorescent dye called ethidium bromide is typically added to the agarose gel before it solidifies. Ethidium bromide binds to the DNA within the gel and fluoresces orange in the presence of ultraviolet light. Thus, ethidium bromide provides a convenient way to visualize the DNA molecules as they separate within the gel.
- The PCR products are loaded into depressions (wells) at one end of the gel. A sample called a molecular marker (DNA ladder) is also loaded into one well of the gel. This molecular marker sample contains DNA fragments of known size for comparison to the PCR product.
- An electric field is applied across the gel. This electric field causes charged molecules to migrate from one end of the agarose gel to another. Typically, the end of the gel near the wells is placed near the negative electrode; the opposite end of the gel is placed near the positive electrode. Since DNA is negatively charged, DNA will migrate from the wells, through the gel towards the positive electrode.
- The DNA samples separate according to size. Smaller DNA molecules migrate farther through the gel matrix than larger molecules.
- The DNA is visualized using ultraviolet light. Ethidium bromide binds to the DNA as the DNA migrates through the gel. The ethidium bromide bound to the DNA fluoresces orange in the presence of ultraviolet light.
If PCR amplification of the β-globin gene was successful, a band of an appropriate size for the β-globin gene will be seen in the agarose gel when the gel is exposed to ultraviolet light.
- What is an agarose gel?
- Describe how DNA molecules separate in an agarose gel.
- Describe how agarose gel electrophoresis can be used to determine if the β-globin gene was successfully amplified by PCR.
Reverse Transcription PCR
PCR can also be used to detect one type of messenger RNA (mRNA) molecule among the mixture of thousands of different mRNA molecules contained within a cell. However, the mRNA molecules from a cell are not used directly as templates for the PCR reaction. For PCR to detect mRNA, a laboratory technique called reverse transcription is done prior to PCR to convert the mRNA molecules within a cell into a collection of DNA molecules called complementary DNAs (cDNAs).
Reverse transcription involves the following steps:
- Purify the mRNA molecules produced by a cell.
- Mix the mRNA molecules with a poly-dT primer. The mRNA molecules produced from eukaryotic genes contain a sequence of approximately 250 adenine bases at the 3’ end of the mRNA (see the Part 10 reading). This sequence of 250 A bases is called a polyA tail. The poly-dT primer is composed of a series of T nucleotides that form hydrogen bonds with the polyA tail on these mRNA molecules.
- Add reverse transcriptase and dNTPs. Reverse transcriptase is a type of DNA polymerase isolated from certain types of viruses (including human immunodeficiency virus) that uses an RNA template to synthesize DNA. The newly synthesized strand of DNA generated by reverse transcriptase is complementary (forms hydrogen bonds) to the mRNA.
- Add ribonuclease H (RNase H) to digest portions of the mRNA. RNase H is a viral endonuclease that recognizes RNA:DNA hybrid molecules and cuts the RNA component. One consequence of RNase H treatment is that the mRNA is cleaved to produce the RNA primers required to synthesize the second DNA strand.
- Add DNA polymerase I and DNA ligase from E. coli to synthesize the second DNA strand. Recall that DNA polymerase I replaces the RNA bases in the primers with DNA bases, while DNA ligase forms the final phosphodiester bonds to convert Okazaki fragments into a continuous DNA strand.
Reverse transcription produces a collection of double-stranded cDNA molecule that correspond to the entire collection of mRNAs in the cell. This collection of various cDNA molecules can then serve as the templates for PCR. Since the primers used in PCR are typically designed to be specific for a particular gene sequence, PCR amplification produces many copies of a single cDNA type, corresponding to a single type of mRNA. In essence, this reverse transcription PCR process has amplified a single type of mRNA from the cell.
Insert a figure here that illustrates reverse transcription PCR.
- What is the starting material for reverse transcription?
- What type of molecule is produced by reverse transcription?
- Describe the function of the poly-dT primer, reverse transcriptase, RNase H, DNA polymerase I, and DNA ligase during reverse transcription.
Often, the goal of PCR is to simply make many copies of a particular DNA sequence. The success of the PCR experiment is determined by analyzing the PCR product on an agarose gel, as described above. In other cases, the goal of PCR is to determine how many copies of the template DNA molecule are present in the original sample, before PCR amplification occurs. To determine the number of template DNA molecules present in a sample, a modification of PCR, called real-time PCR or quantitative PCR (qPCR) is used.
Real-time PCR allows a scientist to monitor the production of PCR products in real-time (i.e., as the reaction is occurring in the thermocycler). If the concentration of template DNA molecules is low in the reaction prior to the start of PCR, then amplification of the target DNA sequence occurs slowly, with detectable products formed in the later PCR cycles. Alternatively, if the concentration of template DNA molecules is high in the reaction prior to the start of PCR, then amplification occurs quickly, with detectable products formed in earlier PCR cycles. Thus, the real-time PCR technique is especially powerful, as it allows researchers to quantitatively measure the concentration of template DNA sequences. If the template molecules are cDNA molecules produced from mRNA by reverse transcription, then real-time PCR can provide a quantitative measure of how actively a gene is transcribed (the more active the gene, the more mRNA products are produced by the gene).
- What is an advantage of using real-time PCR?
Real-time PCR involves a slight modification to the conventional PCR approach. In addition to the five PCR components described earlier, a real-time PCR reaction contains a molecule called a probe. A common probe that is used in many real-time PCR reactions is TaqMan. The TaqMan probe is a short DNA molecule that is designed to form hydrogen bonds with one of the two template DNA strands. The 5’ and 3’ ends of the TaqMan molecule have been modified; the 5’ end of TaqMan is attached to a fluorescent reporter molecule, while the 3’ end of TaqMan is attached to a quencher molecule. When the reporter and the quencher are in close proximity (i.e., within the same probe molecule), the quencher molecule inhibits the fluorescence produced by the reporter molecule. When the reporter molecule is separated from the quencher molecule (i.e., when the probe is degraded by the 5' to 3' exonuclease activity of a DNA polymerase), fluorescence occurs.
During the primer annealing step in a real-time PCR reaction, both a primer and the TaqMan probe binds to one of the two template DNA strands. During the DNA synthesis step, Taq polymerase synthesizes the daughter DNA strand toward the TaqMan probe bound to the template DNA strand. When Taq polymerase encounters the TaqMan probe, Taq polymerase uses its 5’ to 3’ exonuclease activity to begin digesting TaqMan. As the TaqMan probe is digested, the reporter molecule is separated from the quencher molecule and fluorescence occurs. If the number of template DNA molecules in the reaction is low, fluorescence is low in earlier PCR cycles and begins to be detectable in later PCR cycles. If the number template DNA molecules in the reaction is higher, fluorescence is detectable in the earlier PCR cycles.
The thermocycler used in real-time PCR is modified to detect the fluorescence emitted by the reporter molecule as it is released from the quencher molecule during DNA replication.
Insert a figure here that illustrates a real-time PCR cycle.
- What are the six major components of a real-time PCR reaction?
- What are the functions of the two parts of a TaqMan probe?
- Describe how real-time PCR using a TaqMan probe can be used to determine the concentration of template DNA molecules in a reaction?
