10 - RNA Modifications

After the RNA molecule is produced by transcription (Part 9), the structure of the RNA is often modified prior to being translated into a protein product. These RNA modifications apply mainly to eukaryotic RNA transcripts.

Key Questions

  • Which group of organisms modify their RNA transcripts?

Overview of RNA Modifications

The modifications to eukaryotic RNA transcripts include the following:

The remainder of Part 10 will focus on the first three RNA modifications: 5' end capping, 3' end polyadenylation, and RNA splicing.

Figure 10.1 RNA Modifications Overview --- Image used  from OpenStax (access for free at https://openstax.org/books/biology-2e/pages/1-introduction

Key Questions

  • What is the difference between a pre-mRNA and a mature mRNA molecule?
  • What is the difference between an intron and an exon DNA sequence?
  • What is meant by 5’ end capping?
  • What is meant by 3’ end polyadenylation?

5’ End Capping

The 5’ end of the pre-mRNA molecule is modified by the addition of a 7-methylguanosine (7-mG) nucleotide. The process of adding the 7-mG to the pre-mRNA is 5’ end capping. 5’ end capping is the first RNA modification, occurring as soon as the 5' end of the pre-mRNA emerges from RNA polymerase II during transcription. 5’ end capping (see Figure 10.2) involves the following enzymes:

  1. RNA 5’-triphosphatase. Recall that RNA polymerases do not require a primer to initiate transcription (see Part 9).  As a result, the first nucleotide incorporated into the RNA has three phosphate groups attached to the 5' carbon. RNA 5'-triphosphatase removes one of the three phosphates from this nucleotide.
  2. Guanylyltransferase.  Guanylyltransferase cleaves GTP to produce GMP and pyrophosphate (PPi).  Guanylyltransferase then attaches the phosphate group of the GMP molecule to the two phosphate groups on the nucleotide at the 5’ end of the pre-mRNA transcript. It is important to note that an unusual 5’ to 5’ linkage is formed, placing three phosphate groups between the 5' carbons on two adjacent nucleotides.
  3. Methyltransferase.  Methyltransferase attaches a methyl group to the added guanine nitrogenous base, producing the 7-mG cap.

The 7-mG cap has at least three functions.  The 7-mG cap:

Figure 10.2 5' end capping mechanism --- Image created by JET

Key Questions

  • How does the 7-mG structure contribute to translation?
  • Which nucleotide triphosphate provides the energy for 5’ end capping?
  • What is unusual about the covalent bonds between 7-mG and the rest of the pre-mRNA molecule?

3’ End Polyadenylation

The 3’ end of the pre-mRNA is modified by the addition of a polyA tail, a string of approximately 250 adenine (A) nucleotides. The process of adding a polyA tail to the mRNA transcript (see Figure 10.3), called 3’ end polyadenylation, involves:

  1. The detection of two recognition sequences (polyadenylation signal sequences) near the 3' end of the pre-mRNA molecule.  The first polyadenylation signal sequence, 5’-AAUAAA-3’, is recognized by the endonuclease cleavage and polyadenylation specificity factor (CPSF) protein.  The second polyadenylation signal sequence, enriched in guanine and uracil bases, is called the GU-rich sequence. This GU-rich sequence is the binding site for the cleavage stimulatory factor (CstF) protein. When CstF and CPSF bind to their respective polyadenylation signal sequences, CstF activates CPSF.
    • The CPSF protein cleaves the pre-mRNA between the two polyadenylation signal sequences. The new 3’ end of the pre-mRNA is then available for the addition of adenine nucleotides.
    • Poly(A)-polymerase (PAP) attaches 250 adenine nucleotides to the newly generated 3’ end of the pre-mRNA transcript.  PAP is an unusual RNA polymerase that does not require a template and only forms phosphodiester bonds between adenine nucleotides.

    The polyA tail on the mRNA has at least three functions.  The polyA tail functions to:

    The 3’ end polyadenylation process occurs after 5’ end capping, but prior to RNA splicing. In fact, 3’ end polyadenylation assists in terminating transcription in eukaryotes by the torpedo model (see Part 9).

    Figure 10.3 3' end polyadenylation mechanism --- Image created by SL

    Key Questions

    • How does 3’ end polyadenylation contribute to transcription termination in eukaryotes?
    • Describe the functions of CPSF, CstF, and Poly(A)-polymerase during 3' end polyadenylation.

    Splicing of Group I and Group II Introns

    There are three general mechanisms used by eukaryotes to remove introns from RNA molecules. The group I and group II mechanisms are limited to certain types of eukaryotes or certain organelles within a eukaryotic cell. For example, the group I mechanism removes the introns found in ribosomal RNA (rRNA) molecules in certain protozoa. The group II mechanism removes the introns found in the mRNA and transfer RNA (tRNA) transcripts produced by mitochondrial and chloroplast genes. The spliceosome mechanism is the major mechanism that is used to remove introns from pre-mRNA transcripts in the nucleus of eukaryotic cells.

      1. A free guanosine nucleoside (guanine nitrogenous base covalently linked to a ribose sugar; no phosphate groups) binds to a pocket within the intron. The guanosine nucleoside bound to the intron serves as an enzyme cofactor (i.e., assists the ribozyme in catalysis) for the remaining steps in the reaction.
      2. A break forms at the junction between the 3' end of the first exon and the 5’ end of the intron.
      3. The released 3' end of the first exon then cleaves the phosphodiester bond between the 3’ end of the intron and the 5' end of the second exon.
      4. A phosphodiester bond is formed that links the first and second exons together, generating a mature RNA molecule. The intron is released and degraded.
    Figure 10.4 Removing group I introns --- Image created by SL

      1. The 2’-OH group of an adenine nucleotide within the intron cleaves the phosphodiester bond between the 3’ end of the first exon and the 5’ end of the intron. In this reaction, the adenine nucleotide serves as an enzyme cofactor for the reaction.
      2. The released 3' end of the first exon then cleaves the phosphodiester bond between the 3’ end of the intron and the 5' end of the second exon.
      3. A phosphodiester bond is formed that links the first and second exons, generating a mature RNA transcript. The intron is released and degraded.
    Figure 10.5 Removing group II introns --- Image created by SL

    Key Questions

    • What is a ribozyme?
    • Describe the major events that occur in the Group I and Group II splicing mechanisms.
    • What molecules serve as enzyme cofactors in the Group I and Group II splicing mechanisms?

    Removal of Introns by Spliceosomes

    Transcription of most structural genes in the nucleus of eukaryotic cells produces pre-mRNA molecules; the removal of the introns within these pre-mRNA molecules involves a large multi-subunit spliceosome complex. To remove introns from the pre-mRNA, the spliceosome binds to recognition sequences within the intron (see Figure 10.6). These intron recognition sequences include:

    The spliceosome complex contains multiple subunits; these subunits are called small nuclear ribonucleoproteins or snRNPs (“snurps”). Each snRNP within the spliceosome complex is composed of a small nuclear RNA (snRNA) molecule that acts as an RNA enzyme (ribozyme) to remove the introns from the pre-mRNA molecule. snRNPs are also composed of proteins that function to stabilize snRNP structure.

    The spliceosome splicing mechanism occurs as follows:

    1. The U1 snRNP binds to the 5’ splice site within the intron RNA sequence, while the U2 snRNP binds to the branch site adenine within the intron.
    2. Additional snRNPs called U4, U5, and U6 bind to the intron. These five snRNPs (U1, U2, U4, U5, and U6) form the spliceosome complex.
    3. The intron loops out bringing the two exon sequences to be linked close together.
    4. The 5’ splice site within the intron is cut by U1, and the 5’ end of the intron is covalently linked to the 2’-OH group of the branch site adenine, forming an RNA loop structure called a lariat.
    5. The U1 and U4 snRNPs are released.
    6. The 3’ splice site within the intron is cut by the U5 snRNP.
    7. A phosphodiester bond is formed that links the two exons together to form the mature mRNA molecule.
    8. The intron is released along with the U2, U5, and U6 snRNPs.
    Figure 10.6 Spliceosome splicing --- Image created by SL

    Key Questions

    • Which two splicing mechanisms are found in human cells?
    • What are the names of the three RNA sequences found within introns removed by the spliceosome?
    • Which snRNP component is the ribozyme?
    • What are the functions of the U1 and U5 snRNPs?

    Identifying Introns Using R-Loop Experiments

    Introns were initially identified within eukaryotic genes by performing R-loop (hybridization) experiments. These R-loop experiments relied on separating the two DNA strands within a gene, allowing a mRNA molecule to form hydrogen bonds (hybridize) with the template DNA strand, and adding the coding strand DNA, which attempts to form hydrogen bonds with the template DNA strand.  Finally, the resulting nucleic acid structure was examined in an electron microscope.  Below are the results expected from two R-loop experiments, one experiment involving the pre-mRNA (before RNA modifications), the other experiment involving the mature mRNA (after RNA modifications).

    Figure 10.7 R-Loop Results --- Image created by SL

    Key Questions

    • Suppose a gene contains four introns and is hybridized with its mature mRNA. How many R loops would be observed in the electron microscope at the end of an R-loop experiment? How many intron loops would be observed?

    Identifying Introns by Comparing gDNA with cDNA

    Introns within genes can also be identified by comparing the length of a genomic DNA (gDNA) version of a gene to the complementary DNA (cDNA) version of the same gene. gDNA is the version of a gene found in the genome; the gDNA version of a gene contains both introns and exons. cDNA is produced in the laboratory by reverse transcription (see Part 8). Reverse transcription converts mature mRNA into a cDNA molecule using the viral enzyme reverse transcriptase. Since the cDNA molecule is produced from the mature mRNA, cDNA molecules contain exons but lack introns. The gDNA version of the gene, which contains introns, will be longer than the cDNA version of the same gene, which lacks introns.

    The polymerase chain reaction (PCR) technique (see Part 8) can be used to make billions of copies of the gDNA and the cDNA versions of any gene of interest. The gDNA and cDNA PCR products are then separated by size using agarose gel electrophoresis (see Part 8). The size difference between the gDNA and the cDNA copy of the gene can be easily observed on an agarose gel (see Figure 3.2).

    Figure 10.8 Comparing gDNA to cDNA to identify introns.  The gene in question contains a 75 base pair (bp) intron. --- Image provided by K. Mark DeWall

    Key Questions

    • What is the difference between gDNA and cDNA?
    • How can comparing gDNA to cDNA on an agarose gel help you indentify an intron?

    Alternative Splicing

    Alternative splicing involves splicing a single type of pre-mRNA molecule in different ways to produce multiple mature mRNA molecules (see Figure 10.9). Each of these mature mRNAs can then produce slightly different proteins upon translation. These distinct, yet related protein isoforms, all derived from a single gene, can have specialized functions.  Alternative splicing is beneficial in that it allows eukaryotes to carry fewer genes in the genome, permitting a relatively small number of genes the flexibility to encode a vast array of proteins. In humans, it is estimated that 30–60% of the genes in the genome are alternatively spliced. As a result, the human genome, which contains approximately 23,000 structural genes, can produce at least ten times that number of unique protein products.

    One example of alternative splicing involves the splicing of the pre-mRNA molecule for α-tropomyosin, a protein involved in muscle contraction. The human α-tropomyosin gene contains 14 exons (13 introns). There are two types of exons within the α-tropomyosin pre-mRNA:

    Figure 10.9 Alternative splicing allows one gene to produce three proteins. In this example, exons 1, 2, and 5 are constitutive exons, while exons 3 and 4 are alternative exons. --- DNA Alternative Splicing by National Human Genome Research Institue and is used under CC0

    Key Questions

    • Why is alternative splicing advantageous?
    • What are protein isoforms?
    • What is the difference between a constitutive exon and an alternative exon?

    Patterns of Alternative Splicing

    Alternative splicing is regulated by splicing factor proteins. These splicing factor proteins help the spliceosome choose which intron splice sites to cut during RNA splicing. Each cell type has a different collection of splicing factor proteins, allowing different RNA splicing patterns to occur in each cell type.

    Here are some common alternative splicing patterns observed in eukaryotic cells:

    Scientists are still learning the true complexity of alternative splicing.  It appears that alternative splicing patterns are cell-type and developmental stage specific. Moreover, mutations often lead to aberrant splicing patterns. This aberrant splicing produces abnormal protein isoforms and in some cases, disease phenotypes.

    Figure 10.10 Splicing repressor and activator proteins --- Image created by SL

    Key Questions

    • What happens when a splice repressor protein binds to the 3’ splice site within an intron?
    • What effect would a splice activator protein binding to a splice enhancer sequence have on alternative splicing?
    • What is meant by the term mutually exclusive exons?

    Review Questions

    Fill in the blank:

    1. __________________ is an endonuclease that releases the pre-mRNA from RNA polymerase II to terminate transcription.
    2. ____________________ is an enzyme that attaches two nucleotides together via a 5’ to 5’ linkage.
    3. One function of the 7-mG cap is to _______________________________________.
    4. A __________________________ protein prevents the spliceosome from binding to a 3’ splice site.
    5. ________________________ is an enzyme that adds adenine nucleotides to the 3' end of a pre-mRNA. These adenine nucleotides are added in the 5' to 3' direction.
    6. The Group I intron splicing mechanism uses the nucleoside ______________ as a cofactor during catalysis, while the _______________ intron splicing mechanism uses an adenine nucleotide as a cofactor during catalysis.
    7. The U2 snRNP binds to the ________________________ site of the pre-mRNA.
    8. Spliceosome subunits are composed of two components: proteins and _________________.
    9. ______________________ is a pattern of alternative splicing in which an exon is always retained in one cell while that same exon is always skipped in another cell.
